FN01-A: The Extremely Light Front-drive Motor for Road eBikes

The FN01-A motor is a high-intensity front hub motor designed for road bikes and urban bikes. It operates quietly, offers fast speeds, and only 1.8KG.Its rated voltage is 36V, rated power is 250W, and the maximum torque is 35 Nm.

For commute/road/gravel For commute/road/gravel

Extremely Light Extremely Light

Fast and Responsive Fast and Responsive

It is applicable to multiple environments, helping you ride easily

Extremely Light

Extremely Light

TRUCKRUN FN01-A is specially made for high-end road bikes, it weighs only 1.8 KG.

Extremely Light

Responsive

Responsive

TRUCKRUN FN01-A is rated at 250W, with a maximum torque of 32 N.m.

Responsive

Integrated Wheel Available

Integrated Wheel Available

20", 3.9kg. Sleek and natural appearance, reducing installation and maintenance costs

Integrated Wheel Available

Why TRUCKRUN FN01-A stands out as a quiet Commuter eBike motor

Why TRUCKRUN FN01-A stands out as a quiet Commuter eBike motor

...so the power delivery form this bike is better than most other electric bikes that I got to try in the past. So a very smooth power assistance I’m gonna say on top of that. The bike is also very quiet if you’re riding on a flat surface of course. So you don’t hear anything, you don’t hear the motor on the front. It’s a very very quiet bicycle.

Why TRUCKRUN FN01-A stands out as a quiet Commuter eBike motor

RoHS

RoHS

EMC

EMC

SGS

SGS

CE

CE

UL-Certificate

UL-Certificate

UL-Test

UL-Test

EN15194

EN15194

CQC-Hub motor

CQC-Hub motor

CCC

CCC

Quality Management System

Quality Management System

Product parameters

  FN01-A RN02 RN01 RN04 RW29 RW11 RW28 RW26
Dimension diagram

Install Location FRONT Rear Rear Rear Rear Rear Rear Rear
Integrated wheel optional - - - - Optional - -
A (mm) 42.5 40 45.5 36.6 65 68 65 46.3
B (mm) φ102.2 φ121.7 φ104.5 φ125.5 φ191.2 φ158.5 φ191.2 φ192.4
C (mm) φ44 φ44 φ33 φ60 φ44 φ44 φ44 φ44
D (mm) 10.5 15.25 15.25 15.25 15.25 15.25 15.25 15.25
E (mm) 2.5 19.6 42.4 43.7 39.5 39.5 39.5 38.5
OLD (mm) 100 100/130/142 145 135/142 135/175/185/190 135/175/185/190 135/175/185/190 148
Wheel diameter (Inch) 20-29 20-29 20-29 20-29 20-29 20-29 20-29 20-29
Installation mode Front Drive All Fit Cassette Front Drive/Cassette Cassette/Thread on Cassette/Thread on ALL FIT Screwed
Spoke size 28H*13G(12G) 36H*13G(12G) 36H*13G(12G) 28H*13G(12G) 36H*13G(12G) 36H*13G(12G) 12G-13G/36H 12G-13G/36H
Cabling Route Shaft Side Shaft Side/Shaft End Shaft Side Barrel shaft/Shaft Side Shaft Side Shaft End Shaft Side Shaft Side
Rated voltage(Vdc) 36 36 36 36 48 48 48 36/48
Rated power (W) 250 250 250 250 1000/1200/1500 350/500/750 750 500/750
Rated speed(Rpm) 225-325 225-365 255-285 325-380 320-680 240-480 345-520 200-380
Maximum torque(N.m) 32 38 33 28 90 80 70 65
Weight (kg) 1.8 2.1 1.9 2 5.6 3.8 4.2 3.9
Efficiency (%) ≥80 ≥80 ≥80 ≥80 ≥80 ≥80 ≥80 ≥80
Integrated Torque - Optional Optional Optional Optional Optional Optional Optional
Power off brake Optional Optional Optional Optional Optional Optional Optional Optional
Handlebar throttle - - - - Optional Optional Optional Optional
Lights voltage (V/W) - - - - - - - -
Pedal assist function Optional Optional Optional Optional Optional Optional Optional Optional
Noise (dB) <55 <55 <55 <55 <55 <55 <55 <55
IP Level IPX5 IPX5 IPX5 IPX5 IPX5 IPX5 IPX5 IPX5
Operating Temperature (℃) -20-55 -20-55 -20-55 -20-55 -20-55 -20-55 -20-55 -20-55
