The Truckrun M09 boasts monstrous power and explosiveness, providing power support for the world's fastest ebikes. With a maximum torque of 220N.m, it's your best choice for conquering snow-covered terrain and mountain peaks.

mid-drive-motors

M09

M09-Mid Drive Motor

M09 is a true performance beast, available in three versions with 750/1000/1200W, and a maximum torque of 150/200/220N.m. However, don't misunderstand, we haven't designed a motor for an electric motorcycle; this is still an ebike motor. We have found the perfect balance between power and responsiveness. It keenly senses your needs and outputs suitable power. Efficient cooling allows it to operate normally for extended periods, and the operating noise is less than 60 decibels. Its rated voltage is 48~60V to match various systems.

Download

Features Certification Standards Technical Data

Contact

Super Power Super Power

Streamlined Appearance Streamlined Appearance

Comfortable Experience Comfortable Experience

It is applicable to multiple environments, helping you ride easily

Super Power

Super Power

M09 is the most powerful ebike motor of TruckRun Motor so far. It has multiple power options of 1200/1000/750W,and the maximum torque is up to 220N.m. It makes your E-mountain bike easy to climb steep hills, and let the ebike move freely in the sand and snow.

Super Power

Streamlined Appearance

Streamlined Appearance

While providing powerful power, the M09 adopts a special streamlined design that allows heat to be dissipated in time and ensures the motor can run stably for a long time.

Streamlined Appearance

Comfortable Experience

Comfortable Experience

The built-in high-sensitivity torque sensor can be equipped with an ISIS shaft, which can sense changes in pedaling force at any time and adjust the power output to bring a comfortable riding experience to the rider.

Comfortable Experience

Maverick Series M09 Edition

Maverick Series M09 Edition

Smooth all-terrain, the strongest drive system of TruckRun so far.

Maverick Series M09 Edition

Zenith Series M09 Edition

Zenith Series M09 Edition

Specially designed for mountain enthusiasts, powerful and intelligent, mountain legend

Zenith Series M09 Edition

More Details

More Details

More Details

More Details

More Details

More Details

More Details

More Details

More Details

The MONSTER TRUCK of Ebikes!

The MONSTER TRUCK of Ebikes!

Yoto Leopard Review This "Mid-Drive" Ebike is Strong - Haoqi Cheetah Pro Review

The MONSTER TRUCK of Ebikes!

Why TruckRun M09 stands out as a leading ebike motor

Why TruckRun M09 stands out as a leading ebike motor

A review video from 4LEAF bikes: "As a 1200W motor,the bike could goes up to 53km/h by electric mode which means by thumb throttle and over 60km/h with pedalling."

Why TruckRun M09 stands out as a leading ebike motor

Why TruckRun M09 stands out as a leading ebike motor

Why TruckRun M09 stands out as a leading ebike motor

Interview video from EMBN with TruckRun at Eurobike 2023

Why TruckRun M09 stands out as a leading ebike motor

ROHS

ROHS

SGS

SGS

EN15194

EN15194

EMC

EMC

CE

CE

UL-Certificate

UL-Certificate

UL-Test

UL-Test

CQC-Mid-drive motor

CQC-Mid-drive motor

CQC-Hub motor

CQC-Hub motor

CCC

CCC

Quality Management System

Quality Management System

Partner Success Stories: Why Choose TRUCKRUN M09 Mid-drive Motor

Eshion

The TruckRun M09 motor deserves recognition, as our consumers have shown great love for it.

Eshion

Magic Image

The M09 from TruckRun is a powerful motor that exudes a strong sense of muscle. I will never forget the envy in the eyes of others when I rode the demo ebike through the sandy beach.

Magic Image

EUNORAU

TruckRun has deep technical expertise in the field of fat tire bikes, which is why we have chosen them.

EUNORAU

Product parameters

Filter by product name

Filter by product parameters

Reset

  M12 M11 M09 M01 M06 M03 M16 M30
Dimension diagram

Install Location Mid Mid Mid Mid Mid Mid Mid Mid
Size/L*W*H(mm) 192*128*153.5 60*149*135*67.4 233*163*144.5 203*153*135 220*153.5*148 203*153*135 202*126.5*155
Rated Voltage(DCV) 48 36 48-60 36-48 36 36-48 48 60-72
Rated Power(W) 500/750 250 750/1000/1200 250/350/500 250 250/350/500 350/500/750 3000-6000
Rated speed(Rpm) 90-100 100-120 120/135/160 100/100/115 90 100/100/115 110-130 5000-7500
Max Torque(N.m) 120/160 60 150/200/220 100/120/140 95 100/120/140 80-120 30-60
Efficiency(%) ≥80 ≥80 ≥80 ≥80 ≥80 ≥80 ≥80 ≥80
Weight(kg) 3.6/3.9 1.9 5.8/6.0 3.3/3.6/3.8 3.4 3.3/3.6/3.8 3.8
Shaft type ISIS ISIS JIS/ISIS JIS JIS ISIS/JIS ISIS
Noise Grade(dB) <55 <55 <55 <55 ＜60 <55 <55 <55
Power off brake optional optional optional optional optional optional optional
Handlebar throttle optional optional optional optional optional optional optional
Lights voltage (V/W) 6V3W 6V3W 6V3W 6V3W 6V3W 6V3W 6V3W
Pedal assist function optional optional optional optional optional optional optional
Shift monitoring optional optional optional optional Optional optional optional
IP Level IPX6 IPX6 IPX6 IPX6 IPX6 IPX6 IPX6 IPX6
Operating Temperature (℃) -20~55 -20~55 -20~55 -20~55 -20~55 -20~55 -20~55 -20~55
Stator insulation class Class F
