750W hub-drive torque sensor motor for fat-tire ebike. Suitable for building a foldable fat tire ebike.

hub-motors

RW11

RW11-Hub Motor for Fat eBike

RW11 is a torque sensor hub motor designed specifically for fat tire bikes. It operates at a voltage of 48V, with power options of 350/500/750W and a maximum torque of 80N.m. Notably, it boasts a peak power of up to 1200W, delivering the necessary power output when needed.

Download

Features Certification Standards Technical Data

Contact

Designed for All-Terrain Designed for All-Terrain

Good Power Performance Good Power Performance

Quiet yet Powerful Quiet yet Powerful

It is applicable to multiple environments, helping you ride easily

Third-party review: Excellent power.

Third-party review: Excellent power.

A review video by TaiHappy TV: S07-B with TRUCKRUN RW11 750W

Third-party review: Excellent power.

Designed for Fat Ebike

Designed for Fat Ebike

RW11 is a lightweight and high-power torque sensor hub motor designed by TruckRun for fat tires.

Designed for Fat Ebike

Good Power Performance

Good Power Performance

It can help vehicle factory control the costs, and the maximum torque is up to 80N.m.

Good Power Performance

Quiet yet Powerful

Quiet yet Powerful

Quiet yet powerful, the perfect companion for deep forest hunting. The TruckRun RW11 hub motor has a rated power of 750W, with a peak power that can reach 1200W, ensuring quiet operation during regular use while delivering a burst of powerful performance when you need it.

Quiet yet Powerful

ROHS

ROHS

EMC

EMC

SGS

SGS

CE

CE

UL-Certificate

UL-Certificate

UL-Test

UL-Test

EN15194

EN15194

CQC-Hub motor

CQC-Hub motor

CCC

CCC

Quality Management System

Quality Management System

Let customers speak for us.

AOSTIRMOTOR

The TRUCKRUN motor is a perfect match for our G20 & S07-B Fat Tire eBike, and we are highly satisfied with its performance.

AOSTIRMOTOR

TailHappy TV

I’v actually reviewed a lot of ebikes on this channel that are not able to climb this hill under throttle only. So two thumbs up on that.

TailHappy TV

Product parameters

Filter by product name

Filter by product parameters

Reset

  RW11.3H RW03.3H FN01-A RN02 RN04 RW28 RN01 RW29 RW11 RW26
Dimension diagram

Install Location Rear Rear FRONT Rear Rear Rear Rear Rear Rear Rear
Integrated wheel Optional - optional - - - - - Optional -
A (mm) 68 39.5 42.5 40 36.6 65 45.5 65 68 41.6
B (mm) φ158.5 φ140.8 φ102.2 φ121.7 φ125.5 φ191.2 φ104.5 φ191.2 φ158.5 φ163
C (mm) φ44 φ44 φ44 φ44 φ60 φ44 φ33 φ44 φ44 φ44
D (mm) 15.25 15.25 10.5 15.25 15.25 15.25 15.25 15.25 15.25 20.8
E (mm) 39.5 38.5 2.5 19.6 43.7 39.5 42.4 39.5 39.5 40.5
OLD (mm) 135/175/185/190 135 100 100/130/142 135/142 135/175/185/190 145 135/175/185/190 135/175/185/190 148
Wheel diameter (Inch) 20-29 20-29 20-29 20-29 20-29 20-29 20-29 20-29 20-29 20-29
Installation mode Cassette/Thread on Cassette Front Drive All Fit Front Drive/Cassette ALL FIT Cassette Cassette/Thread on Cassette/Thread on Screwed
Spoke size 36H*13G(12G) 36H*13G(12G) 28H*13G(12G) 36H*13G(12G) 28H*13G(12G) 12G-13G/36H 36H*13G(12G) 36H*13G(12G) 36H*13G(12G) 12G-13G/36H
Cabling Route Shaft End Shaft Side/Shaft End Shaft Side Shaft Side/Shaft End Barrel shaft/Shaft Side Shaft Side Shaft Side Shaft Side Shaft End Shaft Side
Rated voltage(Vdc) 48 24/36 36 36 36 48 36 48 48 36/48
Rated power (W) 350/500/750 200/250 250 250 250 750 250 1000/1200/1500 350/500/750 500/750
Rated speed(Rpm) 240-480 200-365 225-325 225-365 325-380 345-520 255-285 320-680 240-480 200-380
Maximum torque(N.m) 80 39 32 38 32 70 33 90 80 65
Weight (kg) 4.0 2.7 1.8 2.1 2.1 4.2 1.9 5.6 3.8 3.9
Efficiency (%) ≥80 ≥80 ≥80 ≥80 ≥80 ≥80 ≥80 ≥80 ≥80 ≥80
Integrated Torque Optional - - - Optional Optional - Optional Optional Optional
Power off brake Optional Optional Optional Optional Optional Optional Optional Optional Optional Optional
Handlebar throttle Optional - - - - Optional - Optional Optional Optional
Lights voltage (V/W) - - - - - - - - - -
Pedal assist function Optional Optional Optional Optional Optional Optional Optional Optional Optional Optional
Noise (dB) ＜55 ＜55 ＜55 ＜55 ＜55 ＜55 ＜55 ＜55 ＜55 ＜55
IP Level IPX5 IPX5 IPX5 IPX5 IPX5 IPX5 IPX5 IPX5 IPX5 IPX5
Operating Temperature (℃) -20-55 -20-55 -20-55 -20-55 -20-55 -20-55 -20-55 -20-55 -20-55 -20-55
